Atlas Copco 1320-7082-25 Main Oil Pump Coupling 6H TB Woods
Atlas Copco 1320-7082-25 Main Oil Pump Coupling 6H TB Woods
SPECIFICATIONS
Coupling Size Code
6
Sleeve Type Code
H
Sleeve Construction
One Piece Solid
Sleeve Material
Thermoplastic Elastomer
Coupling Overall Length
1-7/8 in
Torque Capacity
1800 in
Maximum RPM
6000 RPM
Coupling Outside Diameter
3-3/4 in
Horsepower @ 100 RPM
2.9 hp
Maximum Angular Misalignment
0.016 °
Maximum Parallel Misalignment
0.01 in
Operating Temperature Range
-65 to +250 °F
Atlas Copco 1320-7082-25 Main Oil Pump Coupling 6H TB Woods
SPECIFICATIONS
| Coupling Size Code | 6 |
|---|---|
| Sleeve Type Code | H |
| Sleeve Construction | One Piece Solid |
| Sleeve Material | Thermoplastic Elastomer |
| Coupling Overall Length | 1-7/8 in |
| Torque Capacity | 1800 in |
| Maximum RPM | 6000 RPM |
| Coupling Outside Diameter | 3-3/4 in |
| Horsepower @ 100 RPM | 2.9 hp |
| Maximum Angular Misalignment | 0.016 ° |
| Maximum Parallel Misalignment | 0.01 in |
| Operating Temperature Range | -65 to +250 °F |
-
Available : In Stock.
-
Category : Rubber Parts & Coupling
-
Shipping Area : World Wide.
